Automated series measurement

Stellen Sie die Konformität Ihrer Bauteile auch in der Serienfertigung sicher. Abweichungen im Produktionsprozess können frühzeitig korrigiert und hohe Kosten eingespart werden.

Mit unserer automatisierten Serienmessung prüfen Sie selbst große Stückzahlen und erhalten zuverlässige Messergebnisse in höchster Qualität.

Employees of Q-Tech Roding work in front of the ZEISS METROTOM 1500 computer tomograph

Technologies

KMS

3D scan

“Wir liefern belastbare Ergebnisse, auf deren Basis unser Kunde seine Entscheidungen treffen kann.”

Homepage > Q-Tech Services > Q-Tech Measurements > Specific service

To the point

Damit Sie konstante Bauteilqualität sicherstellen und Abweichungen im Produktionsprozess frühzeitig erkennen, trifft bei Q-Tech ein Höchstmaß an Präzision auf schnelle Messgeschwindigkeit.

Hochpräzise Automatisierungstechnik und unsere exzellenten Mess-Experten bieten die einzigartige Möglichkeit, auch große Stückzahlen auf den Punkt genau zu prüfen und verlässliche Aussagen über die Qualität Ihrer Bauteile zu treffen.

Our competence at a glance

Services

Automatisierte Prüfungsverfahren
Zerstörungsfreies Messen & Analysieren

Advantages

Schnell, reproduzierbar, kostengünstig
Geeigent auch für größere Stückzahlen
Clear and uniform data provision

Our computer tomographs

ZEISS METROTOM 800

X-ray tube: 130 kV
Measuring accuracy: MPE SD(TS): 2.9+L/100 µm
Resolution: 1536 x 1920 pixels (2K detector)
max. measuring volume: [mm] Ø 275 x 360
Accreditation: yes

Determination of dimensional and shape deviations of industrially manufactured products using computed tomography (CT);
Determination of 3D nominal/actual deviations of industrially manufactured products based on CAD data or reference data using computed tomography (CT) and corresponding evaluation software;
Carrying out analyses in the field of shrinkage testing on workpieces using computed tomography (CT);

ZEISS METROTOM 1500

X-ray tube: 225 kV
Measuring accuracy: MPE SD(TS): 4.5+L/50 µm
Resolution: 3072 x 3072 pixels (3K detector)
max. measuring volume: [mm] Ø 615 x 870
Accreditation: yes

Determination of dimensional and shape deviations of industrially manufactured products using computed tomography (CT);
Determination of 3D nominal/actual deviations of industrially manufactured products based on CAD data or reference data using computed tomography (CT) and corresponding evaluation software;
Carrying out analyses in the field of shrinkage testing on workpieces using computed tomography (CT);

Our measuring instruments

ZEISS PRISMO ULTRA

Measuring range: 700 x 1000 x 500 mm
Measuring accuracy: MPE_E: 0.5 +L/500 µm
Probe / Probe head: VAST-Gold
Additional equipment: integrated rotary table
Measuring software: CALYPSO
Accreditation: yes

Determination of dimensional and form deviations of industrially manufactured products using tactile sensors on 3D coordinate measuring systems (KMS) with rotary table

ZEISS PRISMO VERITY

Measuring range: 1200 x 1800 x 1000 mm
Measuring accuracy: MPE_E: 1.3 +L/400 µm
Probe / probe head: ZEISS VAST gold; ZAS; ZEISS RDS-VAST XXT; CFS (DotScan) 3mm
Measuring software: CALYPSO

ZEISS ACCURA 7

Measuring range: 900 x 1200 x 700 mm
Measuring accuracy: MPE_E: 1.6 +L/333 µm
Probe / probe head: RDS probe head with XXT probe, Vast-XT probe head
Measuring software: CALYPSO

ZEISS ACCURA II

Measuring range: 1200 x 1800 x 1000 mm
Measuring accuracy: MPE_E: 2.2 +L/300 µm
Probe / Probe head: VAST-Gold probe head
Measuring software: CALYPSO

ZEISS O-INSPECT 863 in the Q-Tech measurement laboratory

ZEISS O-INSPECT 863 (OPTICAL-TACTILE)

Measuring range: 800 x 600 x 300 mm
Measurement accuracy: MPE_E: 1.7 + L/250 μm
Probe / probe head: VAST XXT tactile probe; Discovery V12 GigE optical zoom sensor; CFS (DotScan) 3mm
Measuring software: CALYPSO

OGP SMARTSCOPE FLASH 200

Measuring range: 200 x 200 x 150mm
Measuring accuracy: X/Y: E2=1.8+6L/1000 µm; Z: E1=3.0 +6L/1000µm
Measurement software: MeasureX measurement software

Our 3D scanner

GOM ATOS Q 8M

Light source: LED
Measuring points per scan: 8 million
Measuring range (mm²) [mm²]: 100 × 70 - 500 × 370
Point spacing (mm) [mm]: 0 .04 - 0.15
Measuring volume: 100, 270, 500
